BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Tên thương hiệu: BOE
Số mẫu: DV280FBM-NB1
MOQ: 10pcs
giá bán: negotiable
Chi tiết bao bì: Đóng gói công nghiệp
Điều khoản thanh toán: T/T, W, Western Union, Moneygram
Thông tin chi tiết
Nguồn gốc:
TRUNG QUỐC
Chứng nhận:
Rohs,CE,FCC
Chất lượng:
Bản gốc hoàn toàn mới
Bưu kiện:
Đóng gói công nghiệp ban đầu
Vật liệu:
kính dẫn
Màu sắc:
16,7m
Người mẫu:
LCM, TFT
Phong cách:
Màn hình LCD thanh
Nghị quyết:
1920*360pixel
Độ sáng:
700CCD/M2
Đầu nối:
51pin
Cuộc sống làm việc:
50 nghìn giờ
Tỷ lệ tương phản:
1200:1
Kích thước màn hình:
28 inch
Khả năng cung cấp:
3000pc mỗi tuần
Mô tả sản phẩm

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life





DV280FBM-NB1 is a 28.0" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Einklcd in the following: Hight Brightness, WLED Backlight, Life ≥ 50K hours, Bar Display , 1/3 cut of 31.5". Based on its features, Einklcd recommend that this model be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc. According to the information stored in einklcd this model mass production on Q1, 2016, Now this model is in production. We inputted this model's specification on May 23 2016 for the first time, and the latest update on Sep 5 2025. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of DV280FBM-NB1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





Brand:BOE
Model P/N: DV280FBM-NB1
Diagonal Size 28.0" (1/3 cut of 32.0")
Panel Type: a-Si TFT-LCD, LCM
Resolution1920(RGB)×360 69PPI Pixel
Format RGB Vertical Stripe
Active Area 699.84(W)×131.22(H) mm
Bezel Opening 704(W)×136(H) mm
Outline Size: 732(W)×165(H) ×17.3(D) mm
Brightness:700 cd/m² (Typ.)
Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Best View on Symmetry
Display Colors: 16.7M 72% NTSC
Frequency 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Weight: 2.40Kgs (Typ.)
Surface
Contrast Ratio:1200:1 (Typ.) (TM)
Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich
VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA
Response Time :8 (Typ.)(G to G)
Lamp Type: WLED , 50K hours , Without Driver
Touch Screen :Without
Application:Digital Signage Outdoor High Brightness Stretched Bar LCD
Signal Interface LVDS (1 ch, 8-bit) , 51 pins Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ;
Storage Temp.: -20 ~ 60 °C
